Raychem EM2-MI Constant Wattage

Raychem EM2-MI constant wattage cable attached to a power lead, coloured red.

EM2-MI is a constant output heating cable for simple, fast, and effective ramp and accessway heating to prevent snow and ice formation.

The pre-terminated EM2-MI cable comes complete with 3m cold leads at each end of the heater, removing the need for on-site termination activities. Simply install the heater over the required area and connect the cold leads to the junction box and “Smart” control unit.

The EM2-MI heating cable is designed for installation in high temperature applications. The product can be installed directly under hot-poured asphalt followed by mechanical high pressure roller.

Product Specifications

Nominal Power 90W/m
Nominal Voltage 230 Vac
Maximum Exposure Temperature 250°C
Minimum Install Temperature -20°C
Circuit Breaker required Type C
RCD 30 mA
Cable Construction Mineral Insulated (MI) heating unit with pre-terminated 3m cold leads.
Certification CE, VDE
Available Products
Product CodeRaychem Part Number
EM2-MI-Pack-26m 075548-000
EM2-MI-Pack-36m 772132-000
EM2-MI-Pack-48m 625519-000
EM2-MI-Pack-60m 375228-000
EM2-MI-Pack-70m 686868-000
EM2-MI-Pack-88m 268364-000
EM2-MI-Pack-123m 1235-99800347
EM2-MI-Pack-136m 1235-99800348
